EP-450XP-P3BR
| Chassis |
Red Coating
|
| Number of Fans |
1 Fan |
| Fan Color |
Blue |
| Case Fan Controller |
3 connecters
|
| M/B Connecter |
20 pins (with
24 pin converter) ATX12V |
| SATA Connector |
2 built in |
| PCIe 6pin
VGA |
Yes (converter
cable) |
| UV Reflective Cable Wrap |
No |
| Top Silent Technology |
23Dba @ 60% Load |
| Over Voltage Protection |
Yes |
| Over Current Protection |
Yes |
| Short Circuit Protection |
Yes |
| Certification |
UL, CE, CB, FCC
|
|
Technical Specification |
| AC Input |
100-120VAC or 200-240VAC
|
| Current |
10/6A
|
| Frequency |
60/50Hz
|
| DC Output |
3.3V |
+5V |
+12V |
-12V |
-5V |
+5VSB |
| Max Output Current |
26A |
45A |
28A |
1.0A |
0.8A |
2.5A |
| Combined Wattage |
220W |
336W |
12W |
4W |
12.5W |
|
Total Wattage |
430W |
22W |
|
450W |
| Dimensions (W x H x D) |
6" x 3.5" x6.25"
|
| Weight |
5 lbs
|
|
|
